Automatic 24 Lambda Wood Pellet Boiler
The Automatik boiler is an innovative product, made with high-quality components for easy connection to central heating systems. The boiler is equipped with a brazier and heat-exchanger self-cleaning. The Lambda version optimizes the combustion process. These boilers are equipped with a touch screen display that allows complete control of the machine and with an anti-condensation valve.
Technical Specification:
| Automatik 24L | Automatik 31L | Automatik 48L | ||
| Heatable Volume | m3 | 560 | 750 | 1100 |
| Heat input (max - min)) | kW | 26,5 - 6 | 34,2 - 6,62 | 54,5 - 14,6 |
| Nominal power (max - min) | kW | 23,9 - 5,5 | 31 - 10,8 | 49,7 - 13,3 |
| Hourly consumption (max - min) | Kg - H | 5,49 - 1,25 | 8,47 - 2,28 | 11,3 - 3,03 |
| Efficiency (max - min) | % | 90,6 - 90,3 | 90,7 - 90,6 | 91,2 - 90,7 |
| Boiler class | 5 | 5 | 5 | |
| Absorption under pressure | mbar | 0,12 | 0,12 | 0,12 |
| Amount of water in the boiler | Lt | 100 | 108 | 135 |
| Exhaust gas temperature at nominal power | °C | 120 | 120 | 120 |
| Exhaust gas temperature at minimum power | °C | 100 | 100 | 100 |
| Boiler resistance (water) for rated power) | mbar | 13 | 10 | 14 |
| Type of fuel | pellet | pellet | pellet | |
| Fuel moisture content (max) | % | 12 | 12 | 12 |
| Furnace Volume | Lt | 1,59 | 2,56 | 2,56 |
| Dimensions of the combustion chamber | mm | 650 x 300 x 300 | 620 x 385 x 385 | 770 x 385 x 385 |
| Combustion chamber volume | Lt | 58,5 | 91,9 | 114,13 |
| Pellet reservoir volume | Lt | 340 | 340 | 340 |
| Ash drawer tray volumes | Lt | 9,3 | 11,6 - 17,7 | 13 - 19,6 |
| Minimum build-up required at the boiler side | EN 303-5, point 4.2.5 | EN 303-5, point 4.2.5 | EN 303-5, point 4.2.5 | |
| Eligibility requirements for Q | W | 1050 | 1100 | 1100 |
| Power supply voltage | Volt | 220 | 220 | 220 |
| Frequency | Hz | 50 | 50 | 50 |
| Dimensions (W x D x H) | mm | 1080 x 1400 x 1560 | 1160 x 1485 x 1560 | 1175 x 1485 x 1560 |
| Net weight | kg | 402 | 455 | 478 |
| Maximum operating overpressure | Bar | 2,5 | 2,5 | 2,5 |
| Test pressure | Bar | 5 | 5 | 5 |
| Maximum operating temperature | °C | 90 | 90 | 90 |
| Chimney pipe | ø mm | 130 | 150 | 150 |
| Supply and return pipe | ø | 1’ 1/4’’ | 1’ 1/4’’ | 1’ 1/4’’ |
| Inlet and outlet connection | ø | 1/2’’ | 1/2’’ | 1/2’’ |
| Heating in operation | with fan | with fan | with fan | |
| Heating equipment operation | under non-condensing | under non-condensing conditions | under non-condensing conditions |
